Air Quality / Microclimate
Particulate Matter (PM) Transmitter (Outdoors)
Outdoor particulate matter (PM) transmitter.
The transmitter is available with analog or digital outputs (or both).
Particulates of sizes PM1.0, PM2.5 and PM10
Also available with an integrated CO2 sensor, 0-5000ppm.
Request A Quote
Ask A Question
Key Specifications
Particulate Measuring Principle
Laser scattering
Particle Size Detection Range
PM1.0, PM2.5 and PM10
Measuring Range
0…1000 µg/m3 (for each pollutant)
Sensor Lifetime
5 years approx when set to 5min cycles (default) | > 10,000 hours in continuous mode (1hz).
Temperature Drift
< 0.01 µg/m3 /°C
CO2 Measuring Principle
Double wavelength NDIR
CO2 Range
0 - 5,000ppm
CO2 Accuracy
±(50 ppm+3% of measurement)
Outputs
RS485 with Modbus-RTU | 4-20mA (0-10Vdc upon special request)
Power Supply (Consumption)
7 - 30 Vdc ( 25mA @ 24Vdc during measurment, 4mA in standby)
Available Accessories
Available Accessories
Request A Quote
Ask A Question
Calibration and service is available for this item.
