Multiparameter Data Logger
Analog / Digital Data logger with color touch screen
The CMC-N16 is one package that can be configured as a Meter + Controller + Data Logger + Human Machine Interface (HMI) + SCADA
Input Range:
- 0/4-20ma
- 0/1 to 5V, 0/1 to 10V
- 0 to 30V
- -10...25 mV, -10...100 mV, 0…600 mV, ±25 mV, ±100 mV
- Pt100, Pt500, Pt1000
- Thermocouples K,S,J,T,N,R
- 0 to 300 ohm, 0 to 3k ohm
Optional Output Range:
- (4) analog 0/4-20mA
- (4) relay 1A/250V
- (4) SSR passive, output compare pulse width modulation
- (4) mixed (2 REL / 2 x 4...20 mA, 2 REL / 2 SSR, 2 x 4...20 mA / 2 SSR)
Communication Interface:
- RS485 / Modbus RTU
- Ethernet RJ45
- Ethernet M12 connector
- Ethernet via gland to RJ45 builit in connector + 2nd RS-485 port
- Ethernet via gland to M12 connector + 2nd RS-485 port
Request A Quote
Ask A Question
Key Specifications
Power supply
16 to 35 VDC, 19 to 50VDC | 85 to 260 VAC
Input type
4 universal inputs | 2 universal pulse counter / tachometer | 5 digital inputs 24V DC
Display
3.5 inch graphic TFT, 16-bit colour, 320 x 240 pixels, with touch screen
Internal memory
4 GB
Data logging interval
0.1 seconds to 24 hours, resolution 0.1 seconds
Communication Protocol
Modbus RTU / Master Modbus RTU / Slave Modbus TCP Server HTTP Web Server NTP
Operating Temperature
0 to 50C | -20 to 50C upon request (conformal coating applied to PCB)
Protection class
IP65
Case material
ABS polycarbonate
Case dimensions
166 x 161 x 103 mm
Available Accessories
Available Accessories
Request A Quote
Ask A Question
Calibration and service is available for this item.
Click here to request an RMA
