2-Channel Thermocouple Meter / Data Logger
Temperature

2-Channel Thermocouple Meter / Data Logger

Model Number
PRO131.2 | PRO 135.2 (Data Logging
Price

$

Standard Lead Time
In Stock
  • Large backlit LCD display has ergonomic wide-angle visibility
    from daylight to darkness.
  • View the data on the display in numeric or chart form or connect to a PC to view the data in real time.
  • PRO135.2 model supports local data logging.
  • Query the data automatically via RS232 commands.
  • The HOLD feature allows freezing the measurements on display, while the REL
    feature allows comparing measurments betwen the channels.
  • Easily switch between units °C, °F and K.
  • Cold junction temperature compensation automatic, and the temperature of the reference junction can optionally be displayed.
  • With the data loggin model (PRO135.2) store up to 1 million data sets.
  • Logged data are stored in excel CSV files that can quickly be retreived and viewed.
  • Large storage capacity: up to 1 million data, file system based.‍
  • The meter is seen by the PC as a mass storage (software not necessary)
  • Automatic log with configurable interval.
  • The meters integrate a Real Time Clock: date and time is stamped for each logged sample.
  • Configurable alarm thresholds and optional hysteresis can be set.
  • LCD Alarm indication and buzzer activation when thresholds are exceeded.
  • Any K, J, T, N, R, S, B and E standard thermocouple probe can be connected.
  • Configurable surface correction factors can be set for use in combination with
    Senseca contact probes, for the best measuring accuracy.
  • Connection to PC Via the USB C port, for viewing or downloading the files stored in the instrument
    internal memory (only PRO 135.2) or connecting to the application software ProXware.

Request A Quote
Ask A Question

Key Specifications

Measuring Range
K: -220.0…+1372.0 °C / -364.0…+2501.6 °F J: -200.0…+1100.0 °C / -328.0…+2012.0 °F N: -200.0…+1300.0 °C / -328.0…+2372.0 °F S: -50…+1750 °C / -58…+3182 °F T: -200.0…+400.0 °C / -328.0…+752.0 °F E: -60.0…+850.0 °C / -76.0…+1562.0 °F B: +300…+1750 °C / +572…+3182 °F R: -50…+1750 °C / -58…+3182 °F
Resolution
0.1 °C / 0.1 °F o 1 °C / 1 °F depending on TC type
Accuracy
±(0.2 °C + 0.2% of measured value) ± 1 digit (J, K, N, T, E) ±(1 °C + 0.4% of measured value) ± 1 digit (S, B, R)
Cold Junction Accuracy
±0.3 °C
Sampling Rate
4 measurements per second
Logging Interval
1, 2, 5, 10, 15, 30 Seconds / 1, 2, 5, 10, 15, 30 min / 1 hour
PC Connection
USB-C
Battery Life
150 hours continuous use
Operating Conditions
-5…50 °C 0…85 %RH non-condensing
Protection Degree
IP67 except probe connection
