Overview of Oxygen &
Combined Oxygen/Carbon Dioxide Analyzers

click on images to see specification pages



{short description of image} Checkmate: High accuracy headspace analyzer for oxygen or oxygen combined with carbon dioxide.
  • Small sample size 1 - 2ml
  • High accuracy for low oxygen
  • 0 - 100% Carbon Dioxide
  • RS232
Checkpoint: Portable headspace analyzer for oxygen or oxygen combined with carbon dioxide.
  • Hand held battery operated
  • 0 - 100% oxygen
  • 0 - 100% Carbon Dioxide
  • sample size 15 ml

http://www.topac.com/checkpoint2.html New Checkpoint II : Portable headspace analyzer for oxygen or oxygen combined with carbon dioxide.
  • Hand held with lithium ion battery power
  • Barcode Scanner
  • Windows PC Interface
  • USB 2.0

MapCheck: General purpose oxygen analyzer 0.1 ppm to 100% oxygen. Recommended for all kinds of inert gas purge systems to monitor the residual oxygen.
  • Continuous monitoring
  • 0 - 100% oxygen
  • RS 232
  • Windows interface
  • High accuracy residual oxygen analyzer for inert gas systems such as nitrogen generators and glove boxes 1ppm to 100% O2
{short description of image} High accuracy online analyzer for oxygen or oxygen combined with carbon dioxide.
  • Continuous monitoring with spot test (single sample) option
  • High accuracy for low oxygen
  • Integrates with packing machine for continuous use
{short description of image} High accuracy online analyzers for residual oxygen in welding, glove boxes and similar applications
  • Continuous monitoring with ppm readout
  • High accuracy for low oxygen



Portable and convenient instrument for checking oxygen concentrations in a variety of applications where lower limits are above 1000 ppm.
  • 0.1-100% oxygen
  • Portable easy to use with one button operation
  • Resolution / Accuracy 0.1% +/- 0.1%
  • Electrochemical sensor
Gas control system for oxygen level integrates oxygen analysis with flow control and gas gas mix
  • Continuous monitoring with ppm readout
  • gas mix and flow control





Oxygen safety monitor
  • hand held battery operated
  • Audible alarm
  • Detects oxygen depletion



Oxygen safety monitors (wall/duct mounting)
  • 0-25% O2
  • Audible Alarm
  • Relay outputs

Calibration and repair service available.
Click the caliper to request an RMA.
